J14 - USB type B connector
PIN
SIGNAL
VBUS (in)
1
D-
2
D+
3
GND
4
J13 - RS232 Serial Connector (DB9F)
PIN
SIGNAL
DTR
1
TX
2
RX
3
N.C.
4
GND
5
DTR
6
N.C.
7
RTS
8
N.C.
9
J7 - Drawer Connector (RJ11)
PIN
SIGNAL
GND
1
N.C.
2
+24 VC
3
IN - CASS
4
SOL-EN
5
GND
6
DESCRIPTION
VBUS (in)
Data -
Data +
Ground signal
DESCRIPTION
Data terminal ready
Data transmission
Data reception
Not connected
Ground signal
Data terminal ready
Not connected
Ready to send
Not connected
DESCRIPTION
Ground signal
Not connected
Power supply
Drawer in
First solenoid
Ground signal
<7>
USB 2.0
2 2
1 1
2
1
3
4
3 3
4 4
J13
5
1
1
6
6
9
J1
1 1
6 6
5
1
9
6
J7
