In order to connect the flexible tubing (B) of "U-
GO" it is sufficient to fit the entrance nozzles' (C)
winglets into the slots provided on the various
components and make sure you hear "CLICK".
In order to disconnect the tubing, press down on
the nozzles' (C) winglets and pull back at the
same time.
When choosing the path of the tubing it is important to choose the shortest one: in general it is preferable for the
tubing to be short rather than long.
Also, the number of curves should be the smallest possible and the curving radii should be large: it is preferable
to have few and large curves rather than many and tight curves; the air passage is eased in this manner.
Pay attention so as to not create any creases or crimped areas.
