Installation
A
C
U P
D O
W N
22 English
DW4000RM(A5)_IB_DD81-02709D-01_EN.indd 22
F
30 mm
E
30°
UP
DO
WN
5. Insert the door brackets (C) on the
custom panel to the holes (E) on the the
dishwasher door to fix the custom panel.
6. While holding the custom panel, attach
it to the door and insert the custom
panel fixers (A) into the holes (F) as
shown in the figure.
7. Push the custom panel downward to fix.
CAUTION
Do not let the custom panel extend
more than 30 mm from the top of the
dishwasher.
8. Adjust the spring level while the door
is approximately opened at 30 degrees.
The door should hold its position, and
should not fall open.
CAUTION
• Do not adjust the spring level while the
door is completely opened.
• If the custom panel weighs more than
5 kg, the door may fall open.
• Custom panels weighing more than 5 kg
are not recommended.
