Johnson Controls VP1000 Bedienungsanleitung Seite 6

Dimensions
Valve Size
VP10xHAA 1/2" DN15
VP10xHDA 1/2" DN15
VP10xHDC 1/2" DN15
VP10xJAJ 3/4" DN20
VP10xJDB 3/4" DN20
A
D
E
Table 1:
Valve dimensions mm.
A B
28 83
28 83
28 85
28 88
28 88
B
C
C
14.5 80.5
14.5 80.5
14.5 93.5
17.5
17.5
5
F
D E
95
95
118
98 118
98 118
P/N 34-636-02537, Rev. A
F
36
36
53
56
56
