SPECIFICATION

Function
0°F to 716°F
Temperature Range
-18°C to 380°C
Accuracy With
-18°C to 10°C (-0.4°F to 50°F): ±2%+1°C (2°F), or ±3°C
ambient operating
(±6°F), whichever is greater (Typical)
temperature of 21°C
>10°C to 380°C (>50°F to 716°F): ±2%, or ±2°C (±4°F),
to 25°C (70°F to 77°F)
whichever is greater (Typical)
±0.5% of reading or ±0.5°C (±1°F), whichever is greater
Repeatability
(Typical)
Display Resolution
0.1°C / 0.1°F
Spectral Response
5μm to16μm
Laser Sighting
Single point laser
Laser Power
Output > 1mW Class 2, wavelength 630 to 670nm
Response Time (95%)
500ms
Distance to Spot (D:S)
10:1
Minimum Spot Size
20mm
Emissivity
0.95
Ambient Operating
0°C to 50°C
Temperature
32°F to 120°F
Relative Humidity
0% to 75% Non-condensing
-20°C to 65°C
Storage Temperature
-4°F to 150°F
(Battery not installed)
Temperature Display
°C or °F selectable
Display Hold
8 sec
MAX/MIN
Temperature Display
Dual LCD Display
LCD Backlit
Low Battery
Indication
Power
9V 6F22 alkaline battery or equivalent
10 hours with laser and backlight on
Battery Life
30 hours with laser and backlight off
Dimension
Approximately 153 x 108 x 40 mm
(H x L x W)
(6.0 x 4.3 x 1.6 in)
Approximately 180 g (0.4 lb)
Weight
with battery installed
