10 Technical data
10.1 General
Die-cast aluminium body
Epoxypolyester powder painting, black colour
Stainless steel screws
Infrared beam wavelength: 850nm
Supplied with instruction manual and 1.5m (4.9ft) of pre-
wired cable
10.2 Mechanical
1 PG9 cable gland
Dimensions (WxHxL):
- IR50 108x124.5x146mm (4.2x4.9x5.7in)
- IR300 213x235x262mm (8.3x9.2x10.3in)
Unit weight:
- IR50 0.9kg / 1.9lb
- IR300 5.3kg / 11.7lb
11 Technical drawings
The values are in millimeters.
j g
108
Fig. 01 IR50
146
VIDEOTEC S.p.A.
www.videotec.com
Printed in Italy
MNVCIR_1025_EN
10.3 Electrical
Power:
- 12Vdc/Vac, consumption 50W (IR50)
- 230Vac, consumption 50W (IR50)
- 230Vac, consumption 300W (IR300)
Lamp duration:
- IR50 2000 hours
- IR300 3000 hours
10.4 Environment
Indoor / Outdoor
Operating temperature: -20°C / +60°C (-4°F / +140°F)
10.5 Certifications
CE EN60065
IP66 EN60529 (IR50 and IR300)
213
Fig. 02 IR300
196 66
