For IR 50W, 230V, the ground harness must not be
removed; but in case this will be necessary, turn
off the power and set the cable in its seat using
the equipped screw or an M3x8mm, equivalent
one.
6.2.1 Achievable distances
Illumination distance achievable depend on the Infra-
Red characteristics of the CCD camera and lens used.
INFRARED BEAM/DISTANCE
IR50SP11
12
IR50FL11
12
IR50WFL11
12
IR50FL2
230
IR300SP2
230
IR300FL2
230
IR300WFL2
230
Tab. 01
* Achievable distance with CCD ½" B/W high sensitive
cameras for night vision, ratio S/N greater than 20dB
and minimum F1.4 lens aperture. The typical distance
of the subject to illuminate is in function of the
reflection coefficient of the illuminated scene.
7  Instructions for normal 

operation

j
g
Colour cameras do not usually sense
infrared light; use black and white cameras.
The efficiency of the spotlights depends very
much on the environment where they are used.
Efficiency increases if installed indoors with
white walls and decreases drastically if installed
outdoors with dark walls and a grass lawn
background.
Some types of autoiris optics can give rise to poor
image definition during the transition from day to
night or vice versa.
10°
10°
20 / 65.6
40°
40°
16 / 52.4
60°
60°
12 / 39.3
40°
40°
16 / 52.4
10°
65 / 213.2
23°
10°
50 / 164
40°
20°
35 / 114.8
8  Maintaining and cleaning
The infrared illuminators are designed to reduce
maintenance to a minimum. The numerous
cooling fins allow optimum dissipation of the heat
generated by the bulb, considerably increasing its
life span.
8.1 Window cleaning
We suggest to use neutral soap diluted with water
or specific products for lens cleaning applied with a
soft cloth.
h
g
Avoid ethyl alcohol, solvents, hydrogenated
hydrocarbide, strong acid and alkali. Such
products may irreparably damage the
surface.
9  Disposal of waste 
materials
This symbol mark and recycle system
n
g
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
5
