look E Post 2 EVO Handbuch Seite 19

INSTALLING A MONOLINK® SADDLE (requires optional adapter kit)
1. Grease the screws (7)
2. Position the Monolink® saddle on the
E-Post 2 EVO (Fig.6)
3. Put both upper brackets (12) in place and
loosely tighten the screw. (Fig.7)
4. Then fix the two lower brackets (11) in
place and loosely tighten the screw.
(Fig.8)
5. Adjust your saddle as necessary. First
block the fore and aft movement by hand
tightening the upper screw, then do the
same with the lower screw once the
desired angle is determined. Tighten the
two screws to the torque of 8Nm. (Fig. 9)
EN
Fig 6
Fig 7
Fig 8
Fig 9
19
