Meter Accuracy:
Voltage:
Current:
LOGIC OUTPUT (TS3023S)
Output Voltage Range:
Output Current:
Output Switch:
Output Terminals:
Sensing:
Over-voltage Protection:
Output Protection:
Load Regulation:
Line Regulation:
Ripple and Noise:
Meter Type:
Meter Resolution:
Voltage:
Current:
Meter Accuracy:
Voltage:
Current:
GENERAL
AC Input Voltage:
Power Consumption:
Operating Range:
Storage Range:
Environmental:
Size:
Weight:
Safety:
EMC:
0·2% of reading + 1 digit.
0·5% of reading + 1 digit
4 to 6 Volts
4 Amps minimum; current limit approximately 5Amps.
Isolates the output and permits output voltage to be set before connecting
the load.
4mm terminals on 19mm (·75") spacing.
Remote via 4mm terminals or direct via shorting links (provided).
Dual-speed circuit giving typically 20msec up to 7 Volts and typically 2usec
above 7 Volts.
Clamped by the over-voltage protection circuit for forward voltages over 7
Volts and up to 3 Amps forward current. Diode clamped for reverse voltages
and up to 3 Amps reverse current.
< 0·5% for 50% load change.
< 0·5% for 10% line voltage change.
< 20mV rms, < 50mV pk-pk.
0·5" 3·5 digit LCD for voltage or current
10mV
10mA
0·5% of reading + 1 digit
0·5% of reading + 1 digit
Internally set for 110, 120, 220, 230 or 240V AC 50/60Hz; operating range ±
10% of setting. Installation Category II.
160VA for single units, 320VA for dual and triple units
5°C to 40°C, 20% to 80% RH
-20ºC to +60ºC
Indoor use at altitudes up to 2000m, Pollution Degree 2.
160mm wide x 160mm high x 238mm deep single unit
308mm wide x 160mm high x 238mm deep dual unit
386mm wide x 160mm high x 238mm deep triple unit
4·9kg single unit; 9·6kg dual unit; 11·0kg triple unit
Complies with EN61010-1.
Complies with EN61326.
3
