The Thandar 'S' series DC supplies are laboratory quality power supplies with remote sensing on all
outputs. The main outputs have dual 0.5" 3.5 digit liquid crystal displays which simultaneously display
output voltage and output current. With the output switch OFF the display can be used to preset the
output voltage and current limit prior to connection of the load. The outputs operate in constant current or
constant voltage mode with automatic cross-over; a display annunciator indicates constant current mode.
Coarse and fine controls permit the output voltage to be set within 5mV and the current limit control is
logarithmic to give good resolution at low current settings. Load and line regulation are better than 0.01
% with ripple and noise typically better than 1mV. Outputs can be switched to be independent or tracking
on those supplies provided with a tracking facility.
The logic supply output has a single 0.5" 3.5 digit liquid crystal display which displays either output
voltage with the output switch OFF or output current with the output switch ON. The output voltage is set
by a calibrated control and a display annunciator indicates current limit. Over-voltage protection is
provided. All outputs are protected against forward or reverse voltages. The power supplies have a steel
case, rubber feet and integral mains lead.

MAIN OUTPUTS

Output Voltage Range:
Output Voltage Setting:
Output Current Setting:
Output Mode:
Output Switch:
Output Terminals:
Sensing:
Output lmpedance:
Constant Voltage:
Constant Current:
Output Protection:
Load Regulation:
Line Regulation:
Ripple and Noise:
Transient Response:
Temperature Coefficient:
Meter Type:
Meter Resolution:
Voltage:
Current:
2
Nominally 0-30V, 0-2A.
By coarse and fine controls; resolution < 5mV across the range.
By single logarithmic control.
Constant current or constant voltage mode with automatic cross-over. A
display annunciator indicates constant current mode.
Isolates the output and permits voltage and current limits to be set up
before connecting the load.
4mm terminals on 19mm (·75") spacing.
Remote via 4mm terminals or direct via shorting links (provided).
Typically <5mΩ at 1kHz.
Typically 50kΩ vvith voltage limit at maximum.
Up to maximum output voltage + 20 Volts forward; diode clamped for
reverse voltages and up to 3A reverse current.
< 0·01 % of maximum output for 50% load change.
< 0·01 % of maximum output for 10% line voltage change.
Typically < 1 mV rms
< 20usec to within 50mV of setting for 90% load change.
Typically <100ppm/°C
Independent autoranging 0·5" 3·5-digit LCDs for voltage and current
indication.
10mV up to 20V, 100mV above 20V.
lmA up to 2A, l0mA above 2A
Introduction

Specification
