96 296
97 297
98 298
99 299
100 300
101 301
102-117 302-317
118 X
119 X
120-135 320-335
136-151 336-351
152-167 352-367
168-183 368-383
184-199 X
The following tables list the values used with the program parameters to specify
modulation destinations and sources.
Mod Destinations
Off
Osc 1 Freq
Osc 2 Freq
Osc 1 and 2 Freq
Osc Mix
Noise Level
Osc 1 Pulse Width
Osc 2 Pulse Width
0 - 4 Unison Mode:
0 1 voice
1 8 voice
2 8 voice detune1
3 8 voice detune2
4 8 voice detune3
0 - 3 Arpeggiator Mode:
0 Up
1 Down
2 Up/Down,
3 Assign
0 - 1 Envelope 3 Repear Mode; off/on
0 - 1 Unison; off/on
0 - 1 Arpeggiator; off/on
0 - 1 Gated Sequencer; off/on
x Unused
0 - 127 Split Point; 60 = C3
0 - 2 Keyboard Mode:
0 Normal 8 Voice
1 Stack
2 Split
0 - 127 Sequence Track1, steps 1 – 16
0 to 125: Normal sequence step value
126 Reset
127 Rest
0 - 126
Sequence Track 2, steps 1 – 16
0 to 125: Normal sequence step value
126
0 - 126 Sequence Track 3, steps 1 – 16
0 to 125: Normal sequence step value
126
0 - 126 Sequence Track 4, steps 1 – 16
0 to 125: Normal sequence step value
126
32 - 127 Name charaters 1 – 16, in ASCII format
Value
0
1
2
3
4
5
6
7
Reset
Reset
Reset
