2 202
3 203
4 204
5 205
6 206
7 207
8 208
9 209
10 210
11 211
12 212
13 213
14 214
15 215
16 216
17 217
18 218
19 219
20 220
21 221
22 222
23 223
24 224
25 225
26 226
27 227
28 228
29 229
30 230
31 231
32 232
33 233
34 234
35 235
36 236
0-103 Oscillator 1 Shape
0 Oscillator Off
1 Sawtooth
2 Triangle
3 Sawtooth/triangle mix
4 – 103 Pulse Wave, Pulse width 0 – 99
0 - 127 Oscillator 1 Glide
0 - 1 Oscillator 1 Keyboard Off/On
0 – 120 Oscillator 2 Frequency, 0 – 120 in semitones (10
octave range)
0 – 100 Oscillator 2 Fine Tune; 0 = -50 cents, 50 = 0
(centered), 100 = + 50 cents
0-103 Oscillator 2 Shape
0 Oscillator Off
1 Sawtooth
2 Triangle
3 Sawtooth/triangle mix
4 – 103 Pulse Wave, Pulse width 0 – 99
0 - 127 Oscillator 2 Glide
0 - 1 Oscillator 2 Keyboard Off/On
0 - 1 Sync off/on
0 - 3 Glide Mode:
0 fixed rate
1 fixed rate auto
2 fixed time
3 fixed time auto
0 - 5 Oscillator Slop
0 - 127 Oscillator 1 - 2 Mix
0 - 127 Noise Level
0 - 164 Filter Frequency, steps in semitones
0 - 127 Resonance
0 - 127 Filter Keyboard Amount
0 - 127 Filter Audio Modulation
0 - 1 Filter Poles 0: 2-pole; 1: 4-pole
0 - 254 Filter Envelope Amount; -127 to +127
0 - 127 Filter Envelope Velocity Amount
0 - 127 Filter Envelope Delay
0 - 127 Filter Envelope Attack
0 - 127 Filter Envelope Decay
0 - 127 Filter Envelope Sustain
0 - 127 Filter Envelope Release
0 - 127 VCA Initial Level
0 - 127 Output Spread
0 - 127 Voice Volume
0 - 127 VCA Envelope Amount
0 - 127 VCA Envelope Velocity Amount
0 - 127 VCA Envelope Delay
0 - 127 VCA Envelope Attack
0 - 127 VCA Envelope Decay
0 - 127 VCA Envelope Sustain
0 - 127 VCA Envelope Release
45
