MIDI Implementation

The Prophet '08 receives MIDI data according to the mode controls under
G . In addition, there is interaction between some of the Program
LOBAL
parameters that determine the overall response of Prophet '08 to MIDI data.
Note: that the Poly Chain output has a number of additional MIDI
messages that are sent when Poly Chain is enabled. These are not
included in the MIDI summary below, since they are specific to use in
Poly Chain mode only.
Following are the Global parameters that affect response to MIDI:
MIDI Channel: ALL, 1...16 –
1 to 16. All receives on any channel.
Poly Chain: Off, Out, In –
by intelligently processing the keys hit and passing MIDI data through to the
Poly Chain MIDI out jack, where it can be routed to a second Prophet '08.
Local Control: Off, On –
the keyboard and panel controls and the synth electronics.
Clock: see table –
sequencer triggers, as follows:
Display
Internal
MIDI Out
MIDI In
MIDIn/Out
MIDI Parameter Send: NRPN, CC, Off –
'08's front panel controls are transmitted via MIDI as Non-registered Parameter
Number (NRPN) controllers or as Continuous Controllers (CC). Transmission of
parameters can also be turned off.
MIDI Parameter Receive: All, NRPN, CC, Off –
Prophet '08 receives parameter changes via MIDI. As with transmission, NRPNs
are the preferred method, though some controllers may only be able to send
CCs.
MIDI Program: Off, On –
changes received, and will transmit Program changes to MIDI Out.
Selects the MIDI channel to send and receive data,
Use this to link two Prophet '08s to double polyphony
Enables or disables the internal connection between
Selects the MIDI clock status, and enables External
MIDI Clock Setting
MIDI clock is neither sent nor received
MIDI clock is sent
MIDI clock is received
MIDI clock is received and transmitted (use
with Poly Chain)
When On, the synth will respond to MIDI program
Changes to the values of the Prophet
Sets the method by which the
39
