MIDI Pressure: Off, On –
(aftertouch) received, and will transmit Keyboard Pressure to MIDI Out.
MIDI Control: Off, On –
and will transmit controllers from the keyboard to the MIDI Out. Controllers
include Pitch Wheel, Mod Wheel, Pedal, Breath, Volume, and Expression.
MIDI SysEx: Off, On –
SysEx messages, and will transmit them, when prompted, to the MIDI Out.

MIDI Messages

System Real-time Messages
Status Description
1111 1000 MIDI Timing Clock
Received Channel Messages
Status Second
1000 nnnn 0kkkkkkk
1001 nnnn 0kkkkkkk
1010 nnnn 0kkkkkkk
1011 nnnn 0vvvvvvv
1100 nnnn 0ppppppp
1101 nnnn 0vvvvvvv
1110 nnnn 0vvvvvvv
Notes: 0kkkkkkk
nnnn
0vvvvvvv
Received Controller Messages
Status Second
1011 nnnn
1011 nnnn
1011 nnnn
1011 nnnn
1011 nnnn
1011 nnnn
1011 nnnn
When On, the synth will respond to MIDI pressure
When On, the synth will respond to MIDI controllers,
When On, the synth will respond to received MIDI
Third
0vvvvvvv
0vvvvvvv
0vvvvvvv
0vvvvvvv
0vvvvvvv
Note number 0 – 127
Channel number 0 to 15 (MIDI channel 1-16). Ignored if MIDI
channel set to ALL
Value
Third
1 0vvvvvvv
2 0vvvvvvv
4 0vvvvvvv
7 0vvvvvvv
74 0vvvvvvv
11 0vvvvvvv
32 0vvvvvvv
Description
Note Off. Velocity is ignored
Note On. Note off if vvvvvvv = 0
Polyphonic Key Pressure
Control Change; see "Received Controller
Messages" table following
Program change, 0 – 127 for Programs 1 – 128
within current Bank
Channel Pressure
Pitch Bend LS Byte then MS Byte
Description
Mod Wheel – directly assignable controller
Breath Controller – directly assignable controller
Foot Controller – directly assignable controller
Volume – Combined with Master Volume and
Voice Volume
Brightness – Added to lowpass filter cutoff
frequency
Expression Controller – directly assignable
controller
Bank Select – 0 and 1 select banks 1 and 2;
others ignored
40
