Program Parameter Data

The following table lists the Prophet '08's voice parameters. These are used for
the NRPNs and in the program and edit buffer dumps. Since most parameters
are present in both the A and B layers, they are listed side-by-side.
A B
0 200
1 201
100 = + 50 cents
0 – 16 MIDI Channel; if = 0, data received on all MIDI
channels. Otherwise = channel number 1 – 16.
0 - 2 Poly Chain
0 No Chaining
1 Poly Chain Out
2 Poly Chain In
0 – 3 MIDI clock select
0 Use Internal clock, don't send MIDI clock
1 Use Internal clock, send MIDI clock
2 Use MIDI clock In
3 Use MIDI clock In, and retransmit MIDI clock out
0 - 1 Local Control Off/On
0 - 2 Parameter Send:
0 NRPN
1 CC
2 Off
0 - 3 Parameter Receive:
0 All
1 NRPN only
2 CC only
3 Off
0 - 1 MIDI Program Send/Receive Off/On
0 - 1 MIDI Pressure Send/Receive Off/On
0 - 1 MIDI Controller Send/Receive Off/On
0 - 1 MIDI Sysex Send/Receive Off/On
0 - 5 Pedal Destination:
0 Foot Control
1 Breath Control
2 Expression
3 Volume
4 Filter Frequency
5 Filter Frequency / 2
0 - 1 Damper Polarity; 0 = normally open, 1 = normally
closed
0 - 3 Velocity Curve
0 - 3 Pressure Curve
Range Description
0 – 120 Oscillator 1 Frequency, 0 – 120 in semitones (10
octave range)
0 – 100 Oscillator 1 Fine Tune; 0 = -50 cents, 50 = 0
(centered), 100 = + 50 cents
44
