2. Product symbols
In this manual and/or on the machine the following symbols are used. These
represent important information about the product or instructions on its use.
600W
Rated output
600W
230-240 V~50 Hz
Rated voltage
230-240 V~
50Hz
0-3000/min
min
-1
Rotational speed
0-3000
Four levels pendulum
action for easier cutting
With a dust extraction
tube to suction the dust
180730_ayce_NC600JS_IM
Cutting capacity on
the steel is 4mm
4mm
Cutting capacity on
the wood is 70mm
70mm
3m cable with Swiss
plug
3M
0-45°bevel base

OPERATION

1. Before use
• Remove any packing material and loose parts from unit.
• Check the accessories before use. They should fit with the machine and your
purpose.
2. Transport of the power tool
• Always wait until the machine has come to a complete stop before placing it down
or transport
• Disconnect the plug from the power source before making any adjustments,
changing accessories, or storing power tools.
• Store idle power tools out of reach children and do not allow persons unfamiliar
with the power tools or these instructions to operate the power tools.
• Store idle power tools in its original packaging in a dark and dry place at above
freezing temperature.
3. Functions
a. Install the blade (Fig. 1)
! Always ensure that the jig saw is switched off and plug is removed
from the power point before making any adjustment.
WARNING
Fig. 1
86 87 |
• It is recommended to wear protective
gloves when inserting or replacing
blade.
• Turn the tool upside so you can access
the jig saw blade.
• Using your thumb and forefinger,
push down the tool-less blade change
catch.
• Slide blade into the locating hole with
the teeth pointing forward, ensuring
that the blade rear edge is located
and supported by the blade roller
guide.
• Release the tool-less blade change
catch to lock the blade in position,
pull on the blade to ensure that it is
fully locked in position and also that
the tool-less blade catch has fully
engaged.
