Inserting batteries

1
Open the battery compartment
and insert batteries
(2 x type AA) according
to the symbols. Be sure
to pay attention to polarity.
1
7
Horizontal and vertical levelling
2
Release the transport restraint, set the ON/OFF switch (4)
to „ON". The laser cross will appear. The laser lines can be
switched individually with the selection button.
LASER
12 EN
2
3
4
5
6
LASER LASER
–
– +
1 Laser line selection button /
Hand receiver mode
2 LED levelling
red: levelling off
green: levelling on
3 Battery compartment
(backside)
4 ON / OFF switch,
transport retainer
5 Laser output windows
6 1/4" tripod threads
(bottom)
7 LED hand receiver mode
