I I n n p p u u t t r r a a n n g g e e – – 1 1 0 0 0 0 . . . . . . + + 1 1 0 0 0 0 m m V V
E E x x a a m m p p l l e e w w i i t t h h 4 4 s s c c a a l l i i n n g g p p o o i i n n t t s s
Input range –100 ... +100 mV
knee input-
points value
1 –50,000
2 20,000
3 70,000
4 80,000
We will use this example in the following
pages
www.kuebler.com
display
value
–250,0
300,0
700,0
950,0
It is recommended to note down the
required pairs of values for the sca-
ling points of the slope before star-
ting the set-up.
