SOFTWARE CONFIGURATION GUIDE
SMART ROOM SYSTEM FOR MICROSOFT LYNC
4. Press the down arrow until you select the SETUP menu, and then press SET.
5. Press the down arrow until you select USB SETTING , and then press the right arrow.
6. Press the left or right arrow until the USB1 option is HDMI1 .
7. Press MENU or EXIT until the on-screen display menu closes.
8. Continue to Configuring Lync Room System software first-run installation settings on page 13.
To start your small room system
1. Flick the power switch on the bottom of the interactive flat panel.
2. Press the Input Select button
front control panel until the input source is HDMI3/PC .
The Lync appliance begins the first-run installation process. During this process, the Lync
appliance restarts several times.
NOTE
This process takes time to complete. During this process, displays might not change
content or might appear blank for several minutes.
3. Press MENU on the interactive flat panel's remote control.
4. Press the down arrow until you select the SETUP menu, and then press SET.
5. Press the down arrow until you select Lync® ROOM RESET , and then press the right arrow.
The on-screen display menu blinks briefly.
6. Press MENU or EXIT until the on-screen display menu closes.
NOTE
Completing steps 3 to 6 configures the interactive flat panel's USB-video mapping, audio
settings, presence detection settings and other settings for use with the
SMART Room System. In addition, completing the above steps disables the volume and
input select controls on the interactive flat panel's front control panels.
7. Continue to Configuring Lync Room System software first-run installation settings on page 13.
6 smarttech.com/kb/170608
on the interactive flat panel's
