SOFTWARE CONFIGURATION GUIDE
SMART ROOM SYSTEM FOR MICROSOFT LYNC
3. Flick the power switch on the bottom of the left interactive flat
panel.
4. Press the Input Select button
input source is HDMI3/PC .
The Lync appliance begins the first-run installation process. During this process, the Lync
appliance restarts several times.
NOTE
This process takes time to complete. During this process, displays might not change
content or might appear blank for several minutes.
5. Press MENU on the left interactive flat panel's remote control.
6. Press the down arrow until you select the SETUP menu, and then press SET.
7. Press the down arrow until you select Lync® ROOM RESET , and then press the right arrow.
The on-screen display menu blinks briefly.
8. Press MENU or EXIT until the on-screen display menu closes.
9. Repeat steps 5 to 8 for the right interactive flat panel.
NOTE
Completing steps 5 to 9 configures the interactive flat panels' USB-video mapping, audio
settings, presence detection settings and other settings for use with the
SMART Room System. In addition, completing the above steps disables the volume and
input select controls on the interactive flat panels' front control panels.
10. Continue to Configuring Lync Room System software first-run installation settings on page 13.
To start your extra large room system
1. Flick the power switch on the bottom of the right interactive flat
panel.
10 smarttech.com/kb/170608
on the left interactive flat panel's front control panel until the
