SMART Room System Konfigurationshandbuch Seite 17

SOFTWARE CONFIGURATION GUIDE
SMART ROOM SYSTEM FOR MICROSOFT LYNC
6. In Control Panel, configure the displays as follows:
IMPORTANT
Align the top of all displays as shown in the above diagram.
o
Set the console as the main display by clicking its thumbnail and then selecting
o
Make this my main display.
Position the console to the right of the interactive flat panels as shown in the above
o
diagram.
You are unable to change these settings later, so ensure you configure the displays
o
correctly.
TIP
To determine which display is which, press Identify. Each display's number appears briefly
on the display.
7. In Control Panel, click Apply and then click OK.
8. In the dialog box, click OK.
The Lync appliance restarts.
9. Type the room system administrator account's password, and then press ENTER.
The Microsoft end user license agreement appears.
10. Read the Microsoft end user license agreement, and then click Accept.
The Lync Admin Console appears.
11. Continue to the next procedure.
15 smarttech.com/kb/170608
