SMART Room System Konfigurationshandbuch Seite 11

SOFTWARE CONFIGURATION GUIDE
SMART ROOM SYSTEM FOR MICROSOFT LYNC
3. Flick the power switch on the bottom of the left interactive flat
panel.
4. Press the Input Select button
input source is HDMI1 .
The Lync appliance begins the first-run installation process. During this process, the Lync
appliance restarts several times.
NOTE
This process takes time to complete. During this process, displays might not change
content or might appear blank for several minutes.
5. Press MENU on the left interactive flat panel's remote control.
6. Press the down arrow until you select the SETUP menu, and then press SET.
7. Press the down arrow until you select USB SETTING , and then press the right arrow.
8. Press the left or right arrow until the USB1 option is HDMI1 .
9. Press MENU or EXIT until the on-screen display menu closes.
10. Repeat steps 5 to 9 for the right interactive flat panel.
11. Continue to Configuring Lync Room System software first-run installation settings on page 13.
To start your large room system
1. Flick the power switch on the bottom of the right interactive flat
panel.
2. Press the Input Select button
panel's front control panel until the input source is HDMI3/PC .
9 smarttech.com/kb/170608
on the left interactive flat panel's front control panel until the
on the right interactive flat
