SOFTWARE CONFIGURATION GUIDE
SMART ROOM SYSTEM FOR MICROSOFT LYNC
7. Set the Lync appliance input's operating mode to PC:
a. Press INPUT, and then press the red button on the remote control, which is below the
BACK button.
The Input Label menu appears.
b. Using the left and right arrow buttons, select HDMI3/PC, and then press OK.
c. Using the left, right, up and down arrow buttons, select PC, and then press OK.
d. Press the down arrow to select Close, and then press OK.
In the Input List menu, the computer input's icon indicates that its operating mode is PC.
IMPORTANT
If you do not complete these steps, the following could occur:
The interactive flat panel might not display the outer edges of the Lync appliance's
o
display.
Users might notice higher than normal video display latency.
o
NOTE
These steps are also documented in Before you configure your SMART Board 8084i-G4
interactive flat panel (smarttech.com/kb/170597), which is included with your room system.
8. Set the options in the PICTURE menu as per SMART's recommendations in appendix B of the
SMART Room System for Microsoft Lync setup and maintenance guide
(smarttech.com/kb/170450).
9. Continue to Configuring Lync Room System software first-run installation settings on page 13.
To start your medium room system with dual panels
1. Flick the power switch on the bottom of the right interactive flat
panel.
2. Press the Input Select button
panel's front control panel until the input source is HDMI1 .
8 smarttech.com/kb/170608
on the right interactive flat
