Mounting Instruction - Nederman EXTENSION ARM Bedienungsanleitung

Mounting
instruction
F3 = 14000 N / screw
a
b
b
6a
2
EXTENSION ARM
180
1
H = 2700 - 3000 mm
3
4
d
c
4,2 m arm: 1010 mm
6,0 m arm: 1900 mm
100 mm
F2 = 1200 N / screw
c
d
2
5
