Front Panel
Louver
Functional Filter
(On Back of Main Filter - Some Units)
Display window
" " when FRESH feature is turned on
" " when defrosting(cooling & heating units).
" " when the unit is operational.
" " when Timer is set.
Displays temperature, operation feature and Error codes:
" "
" " for 3 seconds when:
• TIMER ON is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO feature is turned on
" " for 3 seconds when:
• TIMER OFF is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO feature is turned off
" " when anti-cold air feature is turned on
" " when defrosting(cooling & heating units)
" " when unit is self-cleaning
" " when 8 C heating feature is turned on
NOTE: Different models have different front panel and display window. Not all the indicators
describing below are available for the air conditioner you purchased. Please check the indoor display
window of the unit you purchased.
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly different. The actual shape shall prevail.
Remote Control
(E)
Power Cable (not available)
Remote control Holder
Display Code
Meanings
