5.
I/O connector
6.
Iris connector
7.
Power connector
8.
Power LED indicator
9.
Network LED indicator
10. RS485/RS422 connector
11. Network connector (PoE)
12. Control button (1)
13. Function button (2)
14. microSD Card slot
15. Audio in
16. Audio out
Important
If the Axis product is installed in an external camera housing, leave an unobstructed cylinder-shaped
zone with Ø85 mm (3 3/8 in) around the lens to enable lens movements within the housing.
