3.3 Connections and Power Supply
A24-iTFT
Input:
PE ground must be connected! There is mortal danger by an electrical impact, if the outer
hull of the inlet is damaged e.g. and affects the housing.
Conductor cross section stranded, with ferrule
without plastic sleeve 0,25 mm² - 1,5 mm²
with plastic sleeve 0,25 mm² - 0,5 mm²
Ludwig-Rinn-Straße 10-14 • D- 35452 Heuchelheim/Giessen • Phone: +49 6 41-9 62 84-0 • Fax: +49 6 41-9 62 84-28 • www.tci.de
24 VDC (9-36 VDC),
optionally external power supply 110/230 VAC
