3. Product Description

3.1 Technical Data

The A24-iTFT is an industrial display for panel mounting.
The 24-inch touch screen has got a greater display area and ensures a good readability
and an easier operation for the user.
Display:
Type
Color depth
Hor. freq. / ver. freq.
Input
Resolution
Norm
Touch:
Resolution
Available drivers
Principle
Surface
Connection
Protocol
Specifications:
Environmental
conditions
Storage conditions
Weight
Safety class
Dimensions
Ludwig-Rinn-Straße 10-14 • D- 35452 Heuchelheim/Giessen • Phone: +49 6 41-9 62 84-0 • Fax: +49 6 41-9 62 84-28 • www.tci.de
24"flat panel active matrix TFT LCD
16 mio colors, 8 bit
31,5 kHz – 80 kHz (automatically) / 60 Hz ~ 75 Hz (automatically)
RGB analog, DVI (optionally)
1280 x 1024 / optimally 60 Hz
at least ISO 13406-2 (class II)
12bit
Windows XP, Windows 7, Windows 8, Windows 10, Linux, Android
analog resistive
resistant against chemical agents and dissolvents (acetone,
methylene chloride, methyl ethyl ketone, isopropyl alcohol, hexane,
turpentine, mineral spirits, unleaded gasoline, diesel fuel, motor oil,
transmission fluid, antifreeze)
RS-232, D-SUB, 9 pol.
serial RS-232, 9600 baud
working temperature: 0°C to 50°C
storage temperature: -20°C to 60°C
relative humidity: 5% to 90%, non-condensing
approx. 8 kg
IP65 frontal
see technical drawing
