Bedienungs- und Installationsanleitung
Installation- and Operation Instruction
Beheizter Filter / Heated filter AHF-22
1

Introduction

Sample gas filters are very important components in a sample conditioning system. Hence it is essential to
read this manual carefully and check that all application parameters are completely matched by the
selected gas probe (see data sheet at the end of this manual). In addition check also the shipment and
make sure, that you have received all parts.
This manual refers to various subtypes of the AHF-22 filters. The type of your filter can be found on the
type plate. It always starts with AHF-22 and is followed by the subtype coding e.g. AHF-22-115-R-K.
The coding is:
Regard the specific limits of the filter. Please only order the spare parts matching the probe type.
2

Important advices

Operation of the device is only valid if
−
the product is used under the conditions described in the installation- and operation instruction, the
intended application according to the type plate and the intended use,
−
the performance limits given in the datasheets and in the installation- and operation instruction are
obeyed,
−
monitoring devices and safety devices are installed properly,
−
service and repair is carried out by Bühler Technologies GmbH, unless described in this manual,
−
only original spare parts are used.
This manual is part of the equipment. The manufacturer keeps the right to modify specifications without
advanced notice. Keep this manual for later use. This manual is part of the filter.
Definitions for warnings:
Signal word for important information to the product.
NOTE
Signal word for a hazardous situation with low risk, resulting in damaged to the device or
CAUTION
the property or minor or medium injuries if not avoided.
Signal word for a hazardous situation with medium risk, possibly resulting in severe
WARNING
injuries or death if not avoided.
Signal word for an imminent danger with high risk, resulting in severe injuries or death if
DANGER
not avoided.
Warning against
hazardous situation
Warning against
electrical voltage
Warning against
respiration of toxic gases
Warning against acid
and corrosive
substances
115 Power supply 115V AC
230 Power supply 230V AC
No number: Power supply 115...230V AC
S Self regulating heaters
R Controlled heating (Controller BRS necessary)
K Calibration gas port
BX410006, 04/2007
Warning against possible
explosive atmospheres
Warning against hot
surface
Art. Nr. 90 31 045
disconnect from
mains
wear respirator
wear face
protection
wear gloves
15
