RECARO Expert plus Reha – Instructions for assembly and use of the Reha version
Headrest (height adjustable)
Attach the headrest by placing it in the upper backrest area. Guide both belts and the loops of the belt pads backwards through the provided slots. Fasten them by sliding
the loops of the belt pad onto the metal bar and attaching the belts to the metal hook which is fixed to the strap for the belt adjustment.
The height is adjustable in three stages by changing the height of the shoulder belts.
To adjust the height, pull the bar out of the indentation at the back side. Place the bar either higher or lower and press it into the indentation until it locks in place. Leave
the elastic strap at the bar during adjustment. Now arrange the headrest accordingly.
Note: Do not pull the belt pads to adjust the belts, but the belt straps only.
The cover can be removed and washed in the machine at up to 30° C / 86° F.
Fig. 2a: Fitting the headrest
Lateral trunk supports
Attach the lateral trunk supports by placing them on the seat. Guide both Velcro strips behind the back cover and Velcro-fasten them behind the cover (not behind the
foam).
Just as required, the lateral trunk supports can be used with either the small or the large side facing upwards.
The cover can be removed and washed in the machine at up to 30° C / 86° F.
Fig. 3a: Positioning on the seat
Lateral seat supports
Remove the crotch pad from the belt buckle. Attach the lateral seat supports by placing them on the seat and guiding the belt buckle through the slot provided in the
support. Guide both Velcro strips below the seat cover and Velcro-fasten them behind the cover (not behind the foam). Re-attach the crotch pad to the belt buckle.
Note:
The lateral seat supports can also be used as lateral trunk supports.
The cover can be removed and washed in the machine at up to 30° C / 86° F.
Fig. 4a: Positioning on the seat
Footrest adapter (accessory)
Before assembly, clean the plastic surface on the underside of the seat with commercially available cleaning agents (e.g. water and rinsing agent) until it is completely
free from grease.
Now remove the Velcro strips (fleece) from the adapter plate and attach them to the underside of the seat. The Velcro strips (hooks) remain on the adapter plate.
Position the seat flush in a 90° angle at the front of the adapter (handle of the adapter facing forwards) and tilt the seat over to velcro it to the adapter.
Footrest:
The footrest is attached to the adapter.
Fig. 5a: Attaching Velcro straps to the seat
Footrest, short 12 cm / 4.7" (accessory)
Press the catch springs in at the rear ends of the sliding rods and push the tubes into the holes as far as they will go.
To stabilize the footrest on the vehicle floor adjust the height of the support bars by screwing them in or out until they have contact with the vehicle. Then lock the
support bars with the hand knobs to prevent them unscrewing accidentally. Screw the hand knobs upwards as far as possible and tighten them fast.
Lower leg length:
The lower leg length is adjusted by changing the height of the footrest. Loosen both outer knurled nuts. Retighten them after each adjustment. To achieve the highest
position possible, use the elevation block (+10 cm / 3.9") provided. It is attached centrically on the footrest by Velcro.
Foot angle:
Loosen the 4 screws left and right on the underside of the footrest to adjust the desired foot angle with the rails. Then retighten the screws.
Note:
Always secure the footrest against falling off with the hand knob provided with the user manual. The receiver for the hand knob (metal block with thread) is situated on
the left tube of the footrest adapter.
Fig. 6a: Inserting the support
Seat wedge, bottom (accessory)
The seat wedge is positioned centrically below the car seat. The high edge is at the front to achieve an optimum rest position of the child.
The cover can be removed (zipper) and washed in the machine at up to
30° C / 86° F.
Fig. 7a: Positioning the seat on the seat wedge Fig. 7b: Final position
Table (accessory)
Mount the side parts of the table first, by pulling them over the round corners of the seat. The fabric is attached to three buttons on the side parts of the seat. There are two
buttons on the inside (front and rear, relatively far down) and one on the outside (rear).
Now fasten the table to the Velcro straps of the side parts.
Note:
For reasons of space the crotch pad should be removed when using the table.
The cover can be removed and washed in the machine at up to 30° C / 86° F.
Fig. 8a: Mounting the side parts
6
Fig. 2b: Height adjustment at the seat's back
Fig. 3b: Velcro fastening
Fig. 4b: Velcro-fastening
Fig. 5b: Attaching seat to adapter
Fig. : Adjusting height to vehicle
Fig. 8b: Attaching the table
item code: 866
item code: 806
item code: 810
item code: 811
