REF
PART NO.
PRV NO.
1
86073000
14665
2
86002930
27670
3A
86002400
20064
3B
86002350
20002
4
-
OPEN
5
86063730
27765
6
86235270
28057
7
86003590
34329
8
86237650
35219
9
86237670
35221
10
86004260
39472
11
86156790
40013
12A
86004510
41391
12B
86004450
40019
13
86245660
50911
14
86245670
50912
15
86005640
57030
16
86372080
17
86247910
57044
18A
86004500
41390
18B
86006240
66227
19
86274270
70160
20
86274770
70274
21
86006750
70302
22
86032210
75244
23
86257860
78390
24
86010650
87018
25
86010670
87029
26
86279090
87067
27A
86001370
140408
27B
86001190
140133
28
86003010
27759
29
86240080
39524
30
86004970
50990
SERVICE PARTS LIST
PART NO.
PRV NO.
860256180
28059
QTY
DESCRIPTION
1
BRKT, PT17 SIGHT TUBE
1
CORD, DRAIN PLUG
3
CLAMP, 2.0" WORM GEAR X .312
1
CLAMP, 2.0" NYLON RATCHET
-
-
1
COVER, CMD20 REAR
1
DOME, CMD20
1
FLOAT BALL, VAC SHUT OFF
1
GASKET, 1-1/2 COMPRESSION
1
GASKET, CMD20 DOME
1
HOSE, 1.5 X 24.0 DRAIN
1
HOSEBARB, 3/8MPT X 1/2HOSE
1
HOSE, INSERT
1
HOSEBARB, 1.5 DOUBLE MCHD
1
LABEL, CMD20 RIGHT
1
LABEL, CMD20 LEFT
4
NUT, 10-32 HEX NYLCK
-
1
NUT, 1.5 SLIP JOINT
1
NUT, 3/8 NPT HEX BRASS
1
HOSE,CAP
1
PLUG, DRAIN HOSE
4
SCR, 10-32 X 5/8 PPHMS
6
SCR, 5/16-18 X 3/4 FHMS BLK OX
1
SCR, 5/16-18 X 1.00 HHCS GR5
1
TANK, RECOVERY CMD 20
1
TUBE, 1.5 WASTE
8
WASHER, #10 X 9/16 FLAT
1
WASHER, 5/16 X 3/4 SS
1
WASHER, 5/16 INT STAR
1
BRKT, HOSE HOOK
1
BRKT, RECOVERY HOSE MTG
1
CUFF, HOSE 1.5" BLK A 2126
1
HOSE, 1.5 BLK VAC X 52"
1
LABEL, WINDSOR LABEL DOMED
DESCRIPTION
DOME ASSEMBLY, CMD20
CMD20-I 86038160 01/25/13
RECOVERY TANK ASSEMBLY PARTS LIST
SERIAL NO.
NOTES:
FROM
*
*
*
*
PARTS INCLUDED
(1) 86235270 - PRV NO. 28057
(2) (1) 86237670 – PRV NO. 35221
(3) (1) 86003590 – PRV NO. 34329
49
