Windsor COMMODORE 20 CMD20I Bedienungsanweisung Seite 37

REF PART NO. PRV NO.
1 86233150 20042
2 86063740 27775
3 86197360 31016
4 86197550 40014
5 86197600 40033
6 86004570 44067
7 86013200
8 86245830 50947
9 86005540 54165
10 86005580 56012
11 86197670 56023
12 86270860 57028
13 86005640 57030
14 86006180 66095
15 86006600 70114
16 86274270 70160
17 86274290 70162
18 86006870 70406
19 86197760 78308
20 86258800 84151
21 86010640 87016
SERVICE PARTS LIST
PART NO. PRV NO.
86010560 84158
86026040 54168
SOLENOID AND MANIFOLD ASSEMBLIES PARTS LIST
QTY DESCRIPTION
3 CLAMP, 3/8 WORM GEAR
1 COVER, BURHS MOTOR
1 FI BOW, 1/4 NPT STREET
1 HOSE BARB, 1/4 MPT 3/8
2 HOSEBARB, 1/4 MPT X 3/8H 90DEG
2 JET, MINI PROMAX BODY
- 2 JET, MINI PROMAX 11004
1 LABEL, ADJ INSTRUCTION
1 MANIFOLD, CMD20
1 NIPPLE, 1/4 FPT QD
1 NIPPLE, 1/4 X 1.5
4 NUT, 10-24 TINNERMAN
1 NUT, 10-32 HEX NYLCK
2 PLUG, 1/8 MPT HEX BRASS
2 SCR, #10 X 3/4 PHST TYPE B
1 SCR, 10-32 X 5/8 PPHMS
2 SCR, 10-32 X 3/8 PPHMS SS
4 SCR, #10 X 3/8 PHSM TYPE B BLK
1 TEE, 1/4 STREET
1 VALVE, 230V SOLENOID
3 WASHER, #10 EXT STAR SS
DESCRIPTION
SOLENOID ASSEMBLY 230V
MANIFOLD ASSEMBLY, CMD20
CMD20-I 86038160 08/01/12
SERIAL NO.
NOTES:
FROM
PARTS INCLUDED
(1)86258800-PRV NO. 84151
W/MOLEX CONN
(1)86005540-PRV NO. 54165
(2)86004570-PRV NO. 44067
(2)86013200-PRV NO. NONE
(2)86006180-PRV NO. 66095
(1)86197600-PRV NO. 40033
