REF
PART NO.
PRV NO.
1
86091320
05130
2
86091330
05131
3
86228580
09025
4
86231300
14593
5
86095770
89162
6
86242070
48071
7
86270880
57032
8
86005680
57047
9
86005770
57119
10
86080980
62660
11
86081000
62664
12
86272370
66205
13
86272390
66219
14
86006250
66231
15
86272810
67132
16
86251940
67394
17
86273780
70015
18
86276280
70624
19
86276330
70634
20
86276340
70635
21
86276350
70636
22
86276360
70637
23
86255290
73907
24
86258620
85036
25
86010630
87013
26
86279320
87136
27
86259370
87137
28
86259690
89051
29
86091520
140294
30
86003100
27814
31
86004300
39492
VACUUM SHOE ASSEMBLY PARTS LIST
QTY
DESCRIPTION
1
ARM, BRUSH HOUSING RIGHT
1
ARM, BRUSH HOUSING LEFT
2
BEARING, 1/2 NYLINER SI
2
BUSH, BRZ FLG .50 X .75 X .75
1
COLLAR ASM, HEIGHT ADJUSTMENT
1
KNOB, 1.38 OD X 3/8-16 X 3.00
1
NUT, 3/8-16 HEX FLG
15
NUT, 1/4-20 HEX NYLCK
1
NUT, 3/8-16 HEX NYLCK
1
PLATE, VAC
1
PLATE, VAC TRAP
1
PIN, ROLL 3/16 X 1.13
2
PIN, COTTER HAIR .059 X 1
2
PIN, CLEVIS 1/4 X 1.75
3
RING, 1/2 RETAINING HD SH
1
ROD, VAC PIVOT
4
SCR, 1/4-20 X 3/4 HHCS SS
1
SCR, 3/8-16 X 1.5 CARRIAGE PLTD
5
SCR, 1/4-20 X 1.25 CARRIAGE
2
SCR, 1/4-20 X 2.0 CARRIAGE
2
SCR, 1/4-20 X 2.5 CARRIAGE
2
SCR, 1/4-20 X 1.5 CARRIAGE
1
SPRING, COMP .550 ID X .720 OD X .085W
1
VACUUM SHOE, INSERT
15
WASHER, 1/4 X 5/8 FLAT SS
4
WASHER, .52 X .88 FLAT
1
WASHER, .39 X 1.50 FLAT
2
WHEEL, CMD VAC SHOE
1
BRKT, VAC SHOE ADJUST WELDMENT
1
CUFF, BLK S/C VAC HOSE
1
HOSE, 1.5 BLK VAC X 30
CMD20-I 86038160 04/03/07
SERIAL NO.
NOTES:
FROM
REF. SEE
PAGE 22
REF. SEE
PAGE 22
