REF
PART NO.
PRV NO.
1
86230170
14668
2
86002000
14717
3
86002010
14942
4
86261000
23671
5
86234040
27774
6
86242020
48043
7
86245840
50950
8
86270850
57026
9
86005670
57040
10
86005720
57106
11
86081410
62736
12
86007140
72130
13
86007140
72161
14
86010750
87100
15
86006870
70406
16
86232320
500235
17
86002870
27417
18
86133380
99843
19
86236090
34347
20
86075520
27795
21
86279450
87161
22
86274510
70219
23
86282830
78135
24
86270920
57049
25
86242420
500079
ITEMS NOT SHOWN
PART NO.
PRV NO.
86260960
23521
86002590
23668
86245040
50279
CONTROL PANEL ASSEMBLY PARTS LIST
QTY
DESCRIPTION
1
BREAKER, 8A 250VAC, 50VDC
2
BREAKER, 3A 250VAC, 50VDC
3
BOOT, 3/8 CIRCUIT BREAKER
1
CORD ASM, 230V PIGTAIL
1
CONTROL PROPEL BOARD 115/240V
1
KNOB, SPEED CONTROL
1
LABEL, CMD20 CONTROL PANEL
2
NUT, 8-32 HEX NYLCK
1
NUT, ½ NPT CONDUIT
2
NUT, 8-32 HEX W/ STAR
1
PLATE, CONTROL PANEL
1
SWITCH, SPST 2-POSITION ROCKER
1
SWITCH, KEY DPST
4
WASHER, 3/8 INT STAR
4
SCR,#10 X 3/8 PHSM TYPE B BLK
1
CARD, INSTRUCTION CMD20
1
CORD, 99807 1/8" X 12"
2.8 FT
GASKET, 1/8 X ½ 1SDA FOA, BLK
1
FILTER, EMI 250V 8.5A
1
COVER, PROPEL BOARD
2
WASHER, #6 FLAT SAE
1
SCR, #6 X ½ SHT MTL BLK
1
TRIM, LEFT SCREEN X 33
2
NUT, 6-32 HEX NYLOCK SS
1
LABEL, CIRCUIT BREAKER
QTY
DESCRIPTION
1
CORD ASM, 230V AUST 75ft
1
CORD ASM, 230V EURO 75ft
1
LABEL, GRND SYMBOL
CMD20-I 86038160 04/03/07
SERIAL NO.
FROM
SERIAL NO.
NOTES:
FROM
NOTES:
