O P E R A T I N G I N S T R U C T I O N S
www.conrad.com
Digital diet scales Slim Line
Item-No. 86 00 90
Intended use
The digital diet scales Slim Line serves for weighing and for analysis of nutritional values of food-
in the private sector.
This product is operated only with batteries.
It may only be used indoors; never outdoors. Contact with moisture, such as in bathrooms, must
be avoided.
Any other use than the previously described is not permitted, otherwise there is a risk of short-
circuit, fire, etc.
The product must not be modified or converted, and the casing must not be opened.
The safety instructions must be observed at all times.
This product complies with the applicable national and European specifications.
Safety instructions
In case of damage caused by not complying with these safety instructions the
guarantee will be rendered void. We will not assume liability for any resulting
damage.
We do not assume any liability for material and personal damage caused by
improper use or non-compliance with the safety instructions. The warranty is
voided in these cases.
An exclamation mark in a triangle indicates that there are important instruc-
tions in the operating instructions. Please read all the instructions before
using this device, they include important information on its correct operation.
• Any unauthorized conversion and/or modification of the product is inadmissible for safety and
Q.C. reasons (CE).
• Only use batteries as the voltage source.
• Do not take up operation of the product if it is damaged.
• The manufacturer or supplier will assume no responsibility for incorrect displays or the conse-
quences which arise through an incorrect display.
• Do not use the product in situations in which professional measuring technology is required.
• The device is not suitable for medical or commercial purposes or in the area of professional
sports.
• Before you start a diet, seek advice from your physician on the appropriate procedures. The
diet scales can only support you during a diet, however it is no substitute for professional help.
• The device is not a toy. Children do not understand how dangerous electrical devices can be.
• Avoid exposure to the following:
- heavy mechanical loads
- extreme temperatures
- strong vibrations
- high humidity, dripping or splash water
• Do not leave packing materials unattended. These may become dangerous playing material
for children.
• If you have any questions that are not answered in this instruction manual, please contact our
technical support centre or consult a professional.
Description of features
• Simple weighing and retrieving of nutritional values through pre-programmed nutritional data
of different comestibles
• Integrated nutritional value memory with addition function so that a daily/weekly analysis of all
ingested nutritional values can be effected
• Automatic shut-off after 3 minutes
• Overload display
• Battery charge control
• Warning if the memory capacity is exceeded
Components
Version 01/08
°
(1) On/Off/TARA key
(5) Display for battery charge status
(2) Type of nutritional value
(6) Sum symbol
(3) Comestible code
(7) Display for measured value
(4) Memory indicator
Installing/Replacing batteries
Keep batteries away from children.
Make sure that the polarity is correct when inserting the batteries.
Remove the batteries if the device is not used for a longer period of time.
Leaking or damaged batteries can lead to caustic burning of the skin.
Therefore, use suitable protective gloves.
The batteries must not be short-circuited or thrown into a fire. They must not
be re-charged. There is a danger of explosion.
Do not use batteries with a different charging status or from different manu-
facturers at the same time.
• Open the battery case on the bottom side of the diet scales.
• Remove flat batteries and insert 2 new 1.5 V-Mignon batteries (AA) into the battery case mak-
ing sure the polarity is correct. The correct polarity is imprinted on the bottom of the battery
case.
• Close the battery case.
• If the batteries are discharged, this will be indicated in the display (5) of the battery charge con-
dition. In such case, replace the batteries as described above.
Operation
a) Weighing
• Press the On/Off/TARA key (1). The diet scales runs a
short self-test and then indicates 0 g.
• Put the comestible that you would like to weigh on the
scales. The value display (7) indicates the value.
• To change the scale unit press key „g/oz".
• In order to weigh food in a jar but without weighing the jar itself, you can use the TARE func-
tion.
In order to do so, put the empty jar on the scales and then press the On/Off/TARE key (1). The
measured value is reset to „0". If you now put the comestible into the jar, the scales will indi-
cate the net value for the comestible (without the weight of the jar).
b) Display of the nutritional values
• While weighing a comestible enter the comestible code
according to provided code list by using the numerical
keys on the right-hand side of the display. The entered
code is indicated on the left-hand side at the top of the
display.
If you enter the wrong code, the code will be deleted and the scales displays the
weight again.
• Press the corresponding key on the left of the display in order to retrieve the requested nutri-
tional value. The value is shown in the value display (7) with indication of the corresponding
unit.
KCAL:
Kilo-calories
KJ:
Kilojoules
CHOL:
Cholesterol
:
Protein
:
Carbohydrates
BE:
Carbohydrate exchange
:
Fat
:
saturated fats
:
Sodium
• In order to return to the weighing mode press the key
.
c) Adding nutritional values to the nutritional value memory
• After entering the comestible code, press the key „M+". The nutritional value data are hereby
transferred in the nutritional value memory in accordance with the weighed amount. This is indi-
cated by the memory-indicator (4) in the display.
• In order to add the data of the next comestible, first press the key
, to return to the weighing
mode. Then repeat the above indicated steps.
If the memorey capacity is exceeded, the dis-
play indicates „ERR" and the value is not trans-
ferred to the memory.
d) Retrieving of saved data
• During normal weighing mode press the key „MR".
• Press the corresponding keyes for the nutritional values
that you would like to retrieve. The added values since the
last deletion of the memory are displayed.
e) Deletion of the saved data
• During normal weighing mode press the key „MR".
• The memory is deleted and the memory display (4) switches off as well.
f) Error indicators
• „ERR" in the display indicates that the measuring range
has been exceeded (> 5000g).
• „ERR" with „M" in the display indicates that the value
memory capacity has been exceeded.
Handling
Never use the device immediately after bringing it from a cold to a warm room. The condensa-
tion water created thereby may damage the device.
Leave the device disconnected and wait until it has reached room temperature. Wait until the
condensation water has evaporated.
Maintenance
Make sure that the inside of the device does not get wet or damp.
Externally, the device should only be cleaned with a soft, slightly moistened cloth.
Never use aggressive cleaning agents or chemical solutions as these may damage the surfaces
of the housing.
Disposal
Please dispose of the device, when it is no longer in use, according to the current
statutory requirements.
Disposal of dead batteries/rechargeable batteries
By law, the end-user is required (Battery regulation) to return spent batteries and rechargeable
batteries; it is not permitted to dispose of batteries in the normal waste.
Contaminated batteries/rechargeable batteries are labelled with these sym-
bols to indicate that disposal in domestic waste is forbidden. The symbols
for dangerous heavy metal constituents are: Cd = Cadmium, Hg = Mercury,
Pb = Lead. You can return used batteries/storage batteries free of charge to
any collecting point of your local authority, to our stores or to any other sto-
re where batteries/storage batteries are sold.
Thereby you comply with the legal obligations and you contribute to environment pro-
tection.
Technical data
Operating voltage
3V=
Batteries
2 x 1.5 V Mignon battery (AA)
Item no.: 65 25 02
Power input
1.2μ/12mA (standby/switched on)
Battery lifetime
about 200h (measuring mode)
Measuring range
max. 5000g/11lbs 0.4oz
Definition
1g/2.83g
Minimum display indication
2g
Accuracy
+/-10digit
Memory capacity for nutritional values
Calories
99.999
kJ
99.999
Carbohydrates
9.999.9g
BE:
9.999.9g
Fat
9.999.9g
saturated fats
9.999.9g
Proteins
9.999.9g
Cholesterol
99.999mg
Sodium
99.999mg
Operating temperature
+10 to +40°C
Dimensions
230 x 165 x 25mm
Weight
580g
These operating instructions are published by Conrad Electronic SE,
Klaus-Conrad-Straße 1, D-92240 Hirschau/Germany.
The operating instructions reflect the current technical specifications at time of
print. We reserve the right to change the technical or physical specifications.
© Copyright 2008 by Conrad Electronic SE. Printed in Germany.
