Hardware ReferenceÑFlextight Progression
14
Removing and Replacing the Electrostatic Plate
3. Swing down the electrostatic plate door (shown in Figure 2) by
placing your index Þngers into the left- and right-side gaps behind
the door and pulling forward.
4. Lift the electrostatic plate up and away from the scanner. Place it
someplace safe. Be careful not to bend or fold the plate.
5. Close the electrostatic plate door again.

Replacing the Electrostatic Plate

1. If the ßatbed drawer is closed, press the drawer button (shown in
Figure 1). The ßatbed drawer opens automatically.
IMPORTANT: if a problem occurs when the drawer is opening
(such as an obstruction), you can stop the drawer by pressing the
drawer button again.
2. Open the electrostatic plate door (shown in Figure 2) by placing
your index Þngers into the gap behind the door and pulling for-
ward.
3. Lay the electrostatic plate down over the glass plate. Be careful not
to bend or fold the plate.
4. Make sure the contact pins (labeled A in Figure 5) slip into the
sockets in the electrostatic plate.
Imacon Flextight Progression UserÕs Guide
