Use of the kitchen hood
— The kitchen hood is equipped with a multistage
fan.
Control panel - Fig. 1
a. Indicator light
b. Lighting on/off button
c. Hood on/off button
d. e. f. Button used to adjust
working speed 1 (d.), 2 (e.), 3 (f.)
— For best performance, you are advised to use
speed one or two in normal conditions, and
speed three in the presence of high levels of
vapour.
— Lighting improves visibility in the cooking area,
and should therefore be used.
— It is recommended that you turn the hood on a
few minutes before you start cooking, and
keep it switched on for at least 5 minutes after
you finish.
Use:
Two systems are available
Exhaust mode (A)
Vapours are extracted outside through an
exhausting pipe that is affixed to the connection
ring above the hood.
Diameter of the exhausting pipe must be equal to
that of the connection ring.
In the horizontal runs the duct must be slightly
slanted (about 10°) and directed upwards to vent
the air easily from the room to the outside.
Attention!
If the hood is supplied with carbon filter,
then it must be removed.
Filter version (F)
The air is filtered through a carbon filter (for its
installation see paragraph "Carbon filter") and
recirculated into the room through the grating on
the lower side of the chimney.
Attention!
If the hood is not supplied with carbon filter,
then it must be ordered and mounted.
This version is used when there is no exhaust
duct for venting outdoors or when it is impossible
to install one.
GB
Installation
This cooker hood is designed to be installed onto
a corner of a kitchen.
When installed, the distance between hood and
burners must be not less than 65 cm. above
electric burners or 75 cm. above gas or mixed-
fuel burners.
Electric connection
Before completing any connection, make sure the
house voltage corresponds with the voltage
indicated on the label affixed inside the hood
It is advisable to call a qualified technician to make
the electrical connection.
Appliance fitted with plug.
Connect it to a socket which conforms with
current regulations.
If you intend to connect it directly to the electric
mains, remove the plug and fit an approved
bipolar switch with a minimum contact opening of
no less than 3mm.
If the plug is not accessible once it has been
inserted in the socket, it will however be
necessary to fit an approved bipolar switch with
a minimum contact opening of no less than 3mm.
Appliance without plug
Fit an approved plug or an approved bipolar
switch with a minimum contact opening of not
less than 3mm.
The manufacturers are not liable for any problems
caused by the user's failure to observer the
above instructions.
Warning!
— The hood cannot be connected to flues of
other appliances that run on energy sources
other than electricity.
— When the hood is used at the same time of
other appliances that run on energy sources
other than electricity, provision must be made
for an adequate supply of air.
— No food must be cooked flambé underneath
the hood.
The use of an unprotected flame is dangerous
for the filters and could cause fires.
Therefore, never use an open flame under the
hood. When frying foods, never leave the pan
alone because the cooking oil could flare up.
— Please, keep to the provisions of official
