Cleaning And Maintenance; Technical Specifications - EuroLite LED DL-10 Bedienungsanleitung

If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of LEDs:
Beam angle:
Installation hole:
Minimum mounting depth:
Maximum ambient temperature t
Maximum housing temperature t
Min. distance from flammable surfaces:
Min. distance to lighted object:
Dimensions (LxWxH):
Weight:
Please note: Every information is subject to change without prior notice. 06.03.2008 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady state):
B
230 V AC, 50 Hz ~
29 W
10 x 1 W
approx. 90°
210 mm
120 mm
45° C
60° C
0.5 m
0.1 m
230 x 120 mm
1.3 kg
10/10 00029714.DOC, Version 1.1
