Specifications

• Power supply
10.7 to 16.6 VDC 15 mA nominal, 35mA
with backlight on.
• Operating temperature
0°C to 45°C.
• Size of display
112 x 112 x 20mm (4.4 x 4.4 x 1"). Overall
depth 35mm (1.4") behind panel.
• Display type
Twisted Nematic (TN) grey background,
0°C to +70°C.
• Illumination
Red LED switchable from front panel.
• RF Interference
Less than 6 dB maximum quieting on any
marine radio channel with 3 dB gain antenna
within 1 metre of instrument display head
(European EC specifications).
• Depth
1 to 130 metres, 0.5 to 67 fathoms or 3 to
400ft.
4
• Alarms
Shallow and deep water. Audio and LCD
flag.
• Display unit selection
Feet, metres or fathoms, keypad
selectable.
• Display Damping
Three levels keypad selectable.
• Keel Offset
Keel or waterline, ±9.9 ft, ±1.6 fathoms or
±3.0 metres, user resettable.
• Trend Indication
Arrows indicate increasing or decreasing
depth trend.
• NMEA Outputs
DPT, DBT.
• Proprietary Outputs
Alarm and Trend arrows.
• Transducer
200 kHz, 600 ohm, 1500pF parallel
capacitance.
