WIRING/ CÂBLAGE/ COLLEGAMENTO ELETTRICO/ CABLEADO/ VERDRAHTUNG/ BEDRADING
12 - 24 VDC(CC)
12 - 24 VAC(CA)
Red
12/24V
AC/ DC
Black
RS485 A
Pink
RS485 B
Violet
gnd
Blue
PB
Orange
T1
Brown
T2
Green
NC
Gray
COM
Yellow
NO
White
Red
Black
Pink
Violet
Blue
Orange
Brown
Green
Gray
COM
Yellow
NO
White
ex. 1N4001
Red
Black
Pink
Violet
Blue
Orange
Brown
Green
NC
Gray
COM
Yellow
White
C = 470 nF
R = 10K / ½W
Power supply
Push Button
Tamper
Relay (2 A)
1.
RESET MASTER CODE
2. RS485 termination ON/OFF
(Default - ON=120 ohm)
+
DC
Power
-
Supply
GND
Exit Button
PB
(NO, mechanical or relay dry contact)
-
Electric Door Strike
+
Diode
~
AC
Power
~
Supply
GND
Exit Button
PB
(NO, mechanical or relay dry contact)
~
~
+
V
C
V -
R
~
~
Electro Magnetic Lock
(AC powered)
(DC powered)
3
