PADPROX-AH
Multiprotocol Keypad with integrated proximity reader
SPECIFICATIONS
Technology
Keypad and Proximity (125 KHz, HID or AWID (dipswitch))
Authentication PIN Code, Card, PIN Code or/and Card
Proximity reading type AWID compatible and HID (125kHZ) compatible
Reading distance 2 to 5cm
Interface Wiegand 26, 30, 34, 40bit; Clock&Data
Cable distance 50m
PIN Code Length 1- 8 Digits
Panel Connection Cable, 1m
Green and Red LED Externally Controlled
Orange LED Idle mode
Buzzer Yes
Tamper Yes
Consumption Max. 100mA
IP Rating 65
Power supply 9-14V DC
Operating Temperature -15°C to +50°C
Dimensions (mm) 100 x 94 x 30
Housing Moulded Aluminium
Colour Silver, Red, Green, Dark Grey, Blue, White
SPECIFICHE
Tecnologia Tastiera e prossimità (125 KHz, HID o AWID (dipswitch))
Autenticazione
tessera, codice PIN, tessera e/o codice PIN
Tipo di lettura di prossimità AWID e HID (125kHZ) compatibile
Distanza di lettura da 2 a 5 cm
Interfaccia
Wiegand 26, 30, 34, 40bit; Clock&Data
Distanza cavo 50m
Lunghezza del codice PIN da 1 a 8 cifre
Connessione del pannello
Cavo, 1 m
LED verde e rosso Controllati esternamente
LED arancione Modalità inattiva
Cicalino
Si
Interruttore allarme Si
Consumption Max. 100mA
Classe IP
65
Alimentazione 9-14V DC
Temperatura di funzionamento Da -15°C a +50°C
Dimensioni (mm) 100 x 94 x 30
Alloggiamento Alluminio stampato
Colore Argento, rosso, verde, grigio scuro, blu, bianco
FR
EN IT
User's Manual
Technologie
Authentification
Type de lecture de proximité
Distance de lecture
Interface
Distance de câble
Longueur de code PIN
Câblage
LED vert et rouge
LED orange
Avertisseur sonore
Entrée anti-sabotage
Consommation
Classe IP
Alimentation électrique
Température de fonctionnement
Dimensions (mm)
Boîtier
Couleur
Tecnología
Autenticación
Tipo de lectura de proximidad
Distancia de lectura
Interfaz
Distancia del cable
Longitud del código PIN
Conexión del panel
LED verde y rojo
LED naranja
Buzzer
Tamper
Consumo
Clasificación IP
Alimentación
Temperatura de funcionamiento
Dimensiones (mm)
Carcasa
Color
www.xprgroup.com
ES DE NL
SPÉCIFICATIONS
Clavier et proximité (125 KHz, HID ou AWID (dipswitch))
Carte, Code PIN, Carte ou/et Code PIN
AWID et HID (125kHZ) compatible
2 à 5cm
Wiegand 26, 30, 34, 40bit; Clock&Data
50m
1 à 8 chiffres
Câble de 1 m
Commande externe
Mode ralenti
Oui
Oui
Max. 100mA
65
9-14V DC
-15°C à +50°C
100 x 94 x 30
Aluminium moulé
argent, rouge, vert, gris foncé, bleu, blanc
ESPECIFICACIONES
Teclado y proximidad (125 KHz, HID o AWID (dipswitch))
código PIN, tarjeta, código PIN y/o tarjeta
AWID y HID (125kHZ) compatibile
de 2 a 5 cm
Wiegand 26, 30, 34, 40bit; Clock&Data
50m
de 1 a 8 dígitos
Cable, 1m
Controlado externamente
Modo inactivo
Sí
Sí
Max. 100mA
65
9-14V DC
de -15°C a +50°C
100 x 94 x 30
Aluminio moldeado
Plateado, Rojo, Verde, Gris Oscuro, Azul, Blanco
