GENERAL PRODUCT DESCRIPTION

PERFORMANCE DATA
Function summer / winter.
Luminous signals:
- Yellow localisation function LED.
- Green output status indicator LED (NA contact access closed).
TECHNICAL SPECIFICATIONS
Power supply:
Power absorbed:
Type of relay output:
User connections (load):
Max. wire section at the terminals:
Type of insulation:
Grade of protection:
Pollution:
Regulation range:
Hysteresis:
Temperature operating limits:
Reference standards for CE marking:
EMC EN55014-1 EN55014-2 EN61000-3-2 EN61000-3-3
LVD EN60730-1 EN60730-2-9
(Directive 2006/95/EC - 2004/108/EC)

Functions

230 V~ 50÷60 Hz
2VA
with exchange contact
NA/COM/NC 8 A / 250 V~
2 or 3 wires
2,5 mm
Class II
IP 30
Normal
from +5°C to +35°C
1°C
0°C ÷ +50°C
