INSTALLATION INSTRUCTIONS
Recommendations for positioning:
Install the thermostat at a height of approx. 1.50÷1.70 m from floor level, away from heat
sources, draughts, doors and windows. Do not install on perimeter walls.
OK !
h 1,5 m
A
D
N.B.: The examples given in the following documentation are for illustrative purposes only.
Location advice
B
D
14
C
Heating systems with
thermostat controlling:
A Wall mounted boiler
B Burner
C Circulation pump
D Zone solenoid valve
