SUMMARY
SAFETY INSTRUCTIONS ................................................
1
2 DESCRIPTION. ...................................................................
SPECIFICATION ................................................................
3
a. Monitor
b. Roadside panel
4 INSTALLING .......................................................................
a. Roadside panel
b. Wall-mounted monitor
.......................................................................
WIRING
5
a. Connection
b. Positioning the dip-switches on the back of the monitors
c. Connecting an electric strike or a lock
d. Connecting an automatic gate opener
.............................................................................
USE
6
a. Settings on the roadside panel(s)
b. Settings on the monitor(s)
c. On the monitor(s) you can choose among 4 ring tones
d. Switching off the ring tone on the monitor(s)
e. Operation
f. Optional additional unit
TECHNICAL FEATURES ................................................
7
a. Monitor (VPMN ITOUCH)
b. Roadside panel (VPPLA JCHTOUCH)
c. Power supply
...................................................................p.11
OPTIONS
8
USERS INFORMATIONS
9
MAINTENANCE .........................................................p.11
10
TECHNICAL ASSISTANCE - GARANTEE
11
SAFETY INSTRUCTIONS
12
2GB CFI EXTEL ITOUCH - 12/2009 - V1
p.3
p.3
p.4
p.5
p.6
p.9
p.10
...........................................p.11
..................p.13
..........................................p.13
1
SAFETY INSTRUCTIONS
Important !
Please read the user manual thoroughly before installing or using this product.
If you install this product for other people, please give the manual or a copy to the end user
Warning :
The different elements can only be dismantled by an authorised technician. .
Safety instructions :
To safely use this system, it is essential the fitters, users and technicians follow the safety procedures described
in this manual.
Specific warnings and caution symbols are indicated on the elements if necessary.
2 DESCRIPTION
1 2
Wall-mounted colour hands free monitor (without handset)
Fixing grid of the monitor
230VAC / 17VDC modular adapter
GENERAL INFORMATION
This video door phone is composed of a monitor with its modular adapter and a roadside panel. It allows commu-
nicating with the visitor who calls at the door and controlling the opening of the door and/or gate.
You can develop your installation by adding an optional additional monitor and/or a second roadside panel.
For a safe installation and use, please read carefully these instructions and keep them safe.
CFI EXTEL ITOUCH - 12/2009 - V1
3 4
3GB
