bloom Fresco contemporary Anleitung Seite 19

eng
the button on the back of the footrest, whilst
sliding footrest up or down to your desired
position. The footrest is locked into position
when you hear an audible click. Check footrest
is secured by pulling it downwards.
(c-c5) Safety bar, seat pad & safety harness
assembly
– (#05, #06) Put shoulder straps through the
seat pad slits at the desired height setting.
– Put waist straps through the seat pad slits.
– Place seat pad onto the seat unit.
– Behind the seat pad, slide the buckle on the
end of the shoulder straps into the buckle
slots located on the inner face of seat unit.
Check the straps are secured by pulling on
the straps.
– (#09) Behind the seat pad, pull open storage
compartment door located on the inner face
of seat unit. Slide the buckle on the end of
the waist straps into the buckle slots on either
side of the storage compartment. Close the
compartment door. Check the straps are
secured by pulling on the straps.
– Adjust the length of the harness straps until it
fits snugly around your child.
– (#11) Place left & right "U" shaped bar clips
located on either side of the safety bar onto
the side posts and lock into position. You will
hear an audible click.
– Place buckle on the end of the crotch strap
into the base of crotch bar.
– Press button on base of crotch bar, whilst
sliding base into the seat unit.
6
WARNING: Always use the safety harness.
To remove the seat pad & safety harness for
cleaning, follow the instructions given in the care
& maintenance section of this instruction guide.
(c6-c7) Using and adjusting the safety harness
Locking the safety harness:
Lock the harness by pushing the tongues on
the ends of the waist straps, connected with the
ends of the shoulder straps, into the buckle on
the crotch strap.
The harness will automatically lock when the
tongues have been fully pushed in. You will hear
an audible click.
Unlocking the safety harness:
Squeeze the ends of the tongues together and
then slide them out of the buckle. Your child can
now be removed form the highchair.
Adjusting the shoulder straps height:
As your child grows you will need to alter the
height of the shoulder straps. The time to do this
is when the child's shoulders are above the slits
on the seat pad, where the shoulder straps pass
through.
NOTE: Every time you place your child in the
baby chair or whenever you alter the position
of the seat always check that the harness is
correctly fitted and adjusted using the shoulder
and waist strap buckles. Tighten the harness
until it fits snugly around your child.
