Specification; Controller Functions - DF-models SkyWatcher OPTICAL Flow Anleitung

3. Use of Battery
(1) Please ensure batteries are fitted in the correct orientation as shown
in the instruction manual.
(2) Avoid short circuits by fiting the batteries incorrectly, and do not crush
or squeeze the batteries as this could carry the risk of an explosion.
(3) Do not mix new and old batteries as this can lead to a poor
performance of the product.
(4) Dispose used batteries carefully.
(5) Please keep dead batteries away from heat and fire.
(6) If the device is not going to be used for an extended period of time,
remove batteries to prevent potential damage from battery leakage.
(7) It is recommended to only use the USB charging cable that comes
with the drone to charge the battery.
(8) Don't connect the battery directly to wall outlets or car
cigarette-lighter sockets.
(9) Don't attempt to disassemble or Modify the battery in any way.
(10) Don't use the battery if it gives of an odor, generates heat,
becomes discolored or deformed,or appears abnormal in any way. If
the battery is in use or being charged, remove it from the device or
charger immediately and discontinue use.
Li-Po Battery Disposal & Recycling
Waste Lithium-polymer batteries must not be placed with household trash.
Please contact local environmental or waste agency or the supplier of your
model or your nearest Li-Po battery recycling center.
2

Specification

Drone
Item no.: 9220
Weight: 80g
Battery: Li-po,3.7v 1000mAh
Max Flight Time: 10 mins
Charging time: 150 mins
Hovering: Enabled
o
Operating Temperature Range: 0 to 40 C
Dimensions: 180x 170x 38mm

Controller functions

speed-select button
throttle
left stick
LED
calibration
video
power swith
headless mode
speed-select
button
Transmitter
Operating Frequency: 2.4GHz
Max transmission distance: 40m
Battery: 1.5V AAA (not included)
o
Operating Temperature: 0 to 40 C
o
optical flow mode /
normal mode
right stick
trim
one key start
one key stop
flip button
optical flow mode /
normal mode
3
o
