Main parts (Fig. 1, Fig. 2, Fig. 3, Fig. 4)
Motor housing
1
Doser
2
Bean hopper
3
Support fork
4
Dosing lever
5
Grinding adjustment disc
6
Disc locking knob
7
Bean hopper shutter
8
ON-OFF (I-O) switch
9
10 Stopping blade
14
15
1
Fig. 1

COFFEE GRINDER

*
3
11
Dose regulating knob
12
Start button
13
Tray
14
Hopper lid
15
Doser lid
16
Time setting knob**
17
Amperometric circuit breaker
(if available)
Only on automatic models
*
Only on timed models
**
