VARI LITE - VL440 / VL770 / VL880 L
24.26 in
616.2 mm

Floor Mounting the Luminaire

All luminaires included in this manual are designed to sit directly on its base in a floor installation
application. When used in this type of application, be sure to leave enough space around the luminaire
to allow proper, uninterrupted airflow for cooling and movement.
24
UMINAIRE
23.00 in
584.2 mm
Figure 2-10: Hanging Dimensions and Clearances
31 Octo be r 20 13
U ' M
SER S ANUAL
18.88 in
479.5 mm
22.25 in
565.2 mm
Safety Cable:
Recommended for hanging installations.
May be required by local codes. Safety
cable is sold separately.
02 .9 687 .00 01 C
