7. Technical data
7.� Dimensions and weights
Function
Dimensions (H x W x D)
Weight
noise emission
7.2 Power pack
Function
Input voltage
Input frequency
Output voltage
Operating temperature
7.� Measuring functions
Measurement function
Rotation speed
Oil temperature
U battery
U-term. 15
U-term. 1
Closing angle
Closing time
Ignition point,
Ignition advance with stroboscope
Start of delivery, start of injection,
Injection timing with stroboscope
7.� Multimeter functions
Measurement function
U-DC/AC
min./max.
Resistance
Robert Bosch GmbH
Specification
1785 x 680 x 670 mm
91 kg
<70 dB(A)
Specification
90 VAC — 264 VAC
47 Hz — 63 Hz
15 V
0 — 40 °C
Measurement range
450 rpm — 6000 rpm
100 rpm — 12000 rpm
250 rpm — 7200 rpm
–20 °C — 150 °C
0 — 72 V
0 — 72 V
0 — 20 V
0 — 100 %
0 — 360°
0 — 50 ms
0 — 60 °KW
0 — 60 °KW
Measurement range
±200 mV — ±20 V
±20 V — ±200 V
0 — 1 kΩ
1 kΩ — 10 kΩ
10 kΩ — 999 kΩ
Technical data | BEA ��� � BEA ��� E��� | �7 BEA ��� � BEA ��� E��� | �7
�esolution Sensors
10 rpm Connecting cable B+/B‒
10 rpm Trigger clamp,
secondary sensor,
Connecting cable terminal 1
10 rpm Diesel clip-on sensor
0.1 °C Oil temperature sensor
0.1 V Connecting cable B+/B–
0.1 V Connecting cable terminal 15
50 mV Connecting cable terminal 1
0.1 % Connecting cable terminal 1
0.1 °
0.01 ms Secondary sensor
0.1 ms Current clamp 30 A
0.1 °KW Trigger clamp
0.1 °KW Clip-on sensor
�esolution Sensors
0.001 V Multi measuring cable CH1
=.01 V
0.001 Ω Multi measuring cable CH1
0.01 Ω
0.1 Ω
| �7 en
|
1 689 989 034 2008-08-11
