Standard operation control
0x70
sub Name
AD_SPC - Analog
Signal Set Point
Value
1 SP1 - set point
value 1
2 SP1 - set point
value 2
AD_SPC - Analog
Signal
Configuration
1 Analog Output
Mode
2 Error Value
Hysteresis
3 Error Replacement
Values
Measurement
Data Collection
1 Position value
2 Signal quality
3 BD1 status
4 BD2 status
5 BD3 status
Output
Configuration
1 Output Type Q1
2 Output Type Q2
3 Output Type Q3
4 Analog Output Type
U
Data
Type type Value
R/W record
R/W uint16 0 ... 448
R/W uint16 0 ... 448
R/W record
R/W uint8 0x00 - Rising
Ramp
0x01 - Falling
Ramp
R/W uint16 0: Normal
1: Medium
2: High
R/W uint8 0b0000 0000 -
disabled
0bXXXX XXX1 -
out-of-range
enabled
0bXXXX XX1X -
no target enabled
R record
R uint16 0 ... 448
R uint8 0x00 - insufficient /
no position
acquisition
possible
0x01 - acceptable
0x02 - good
0x03 - excellent
R uint8 0: inactive
1: active
R uint8 o: inactive
1: active
R uint8 0: inactive
1: active
R/W record
R/W uint8 0x00 - push-pull
0x01 - low-side
0x02 - high-side
R/W uint8 0x00 - push-pull
0x01 - low-side
0x02 - high-side
0x03 - hi-Z
R/W uint8 0x02 - high-side
0x03 - hi-Z
R/W uint8 0x03 - U: 0...10V
0x04 - U: 1...5V
Default Unit
0
448
0x00
0
0
1/32mm
0x00
0x00
0x02
0x03
